Toshiba Inverter Air Conditioner Super Daiseikai 9 series 10000 (9000) btu A+++/A+++ Wi-Fi Optional RAS-10PKVPG-E/RAS-10PAVPG-E - NEW

Toshiba Inverter Air Conditioner Super Daiseikai 9 series 10000 (9000) btu A+++/A+++ Wi-Fi Optional RAS-10PKVPG-E/RAS-10PAVPG-E - NEW

Technical features

Model :

• Indoor Unit Code: RAS-10PKVPG-E
• Outdoor Unit Code: RAS-10PAVPG-E
• Wi-Fi Optional (RB-N106S-G)

Cooling performance

• Nominal Capacity: 2.5 kW
• Min - Max capacity: 0.80 - 3.50 kW
• Absorbed Power (Min - Nominal - Max): 0.15 - 0.45 - 0.82 kW
• SEER: 10.60W
• Energy Efficiency Class: A+++
• Annual energy consumption 83 kWA

Heating performance

• Nominal Capacity: 3.2 kW
• Min - Max capacity: 0.70 - 5.80 kW
• Absorbed Power (Min - Nominal - Max): 0.15 - 0.60 - 1.55 kW
• SCOP : 5.2W
• Energy Efficiency Class: A+++
• Annual energy consumption 807 kWA

Indoor unit features:

• Air flow (a) (CH) m3/h 690 - 720
• Sound pressure level (qa) (C) dB (A) 20 - 24 - 43
• Sound power level (CH) dB (A) 58 - 59
• Dimensions (H × W × D) 293 x 851 x 270 mm; 14kg

Outdoor unit features:

• Air flow (a) (CH) m3/h 2160 - 2160
• Sound pressure level (CH) dB (A) 46 - 47
• Operating range (C) °C -15 ÷ 46
• Operating range (H) °C -15 ÷ 24
• Dimensions (H × W × D) mm630 x 800 x 300; 38kg
• Liquid/gas pipe diameter 1/4 - 3/8
• Maximum height difference 15 m

SUPER DAISEIKAI 9

Toshiba has always been synonymous with technological innovation, high quality and reliability of its products. The Daiseikai heat pump family represents the performance excellence of the Toshiba brand. The Daiseikai models satisfy all those characteristics highly appreciated today by advanced and environmentally conscious consumers, starting with the low environmental impact R32 gas. All the main components are entirely designed by Toshiba, and reflect the high standards of quality, reliability and precision of Japanese technology. The Daiseikai family consists of two models: Super Daiseikai 9, with three sizes up to class A+++/A+++, and Daiseikai Light with six sizes up to A++/A++. These systems are capable of heating and cooling the environment throughout the year and in any conditions up to -15°C in winter and +46°C in summer. The pleasant aesthetics and the glossy panel of the units allow them to be placed in any environment. A small LED light, located on the flat front, indicates, by changing its colour, the selected operating mode: red for the hot function, blue for the cold one

Super Daiseikai 9 is the heating and cooling system designed for those seeking the highest performance, well-being and air quality, with particular attention to the aesthetic aspect. Equipped with a plasma purifier, Super Daiseikai 9 reduces impurities, which are electrically charged via plasma polarization, and deposit on the battery, from which they are then eliminated. Toshiba engineers have equipped it with all the functions designed to achieve comfort
ideal. Thanks to the simple to use remote control, with a large, backlit display, you can set the
various functions such as:

• Fireplace: innovative Toshiba function, evenly distributes the temperature within the environment in the presence of another heat source.
• 8°C antifreeze: keeps the temperature constant between 5°C and 13°C, ideal for finding a welcoming environment when returning home.
• 3D Air Flow: manages the air flow in 6 different air distributions.
• Power Select: reduces energy absorption by up to 50%, facilitating simultaneous use with other appliances in the presence of low power meters.
• Weekly programming: allows you to set up to four events for each day of the week.

Magic Coil & Self-Cleaning

The Daiseikai range is designed to last over time, always guaranteeing excellent performance, ideal and constant temperature, as well as high quality of the air released into the environment. To do this, the battery is covered with a special Magic Coil layer which prevents the deposit of dirt and dust and facilitates its disposal. Furthermore, the Self-Cleaning function is activated when the unit is turned off: the internal unit fan continues to operate to remove humidity. All this, combined with the purification system, keeps the unit dry and clean.

• Very high energy efficiency in class A+++/A+++
• Very high SEER performance up to 10.60 and SCOP up to 5.20
• 3 sizes cooling capacity from 2.5 to 4.5 kW and heating capacity from 3.2 to 4.5 kW
• Extremely silent with only 20 dB(A) of sound pressure

• peso: 50.0 kg
• classe energetica raffreddamento: A+++
• classe energetica riscaldamento: A+++
• costospedizionecad: IT35;AD165;AT106;BE111;BG136;HR123;DK175;EE170;FR144;DE102;LV131;LT123;LU80;NL119;PT114;CZ90;SK101;SI101;ES104;SE212;HU85;CH168;
• gas: R-32
• marca: Toshiba
• modello: RAS-10PKVPG-E/RAS-10PAVPG-E
• potenza btu: 9000
